High quantity Gas Separation Zeolite Molecular Sieves13X , szie 1.6-2.5mm
Introduction
A main component of X-type molecular sieve is aluminosilicate, silicon-oxy and alumina tetrahedron to form a FAU-type structure the main crystal structure is twelve membered rings.
In molecular sieve 13X, sodium ion formation with a pore opening of 9-10Å (1Å=1×10-10m), that is type 13X (also known as NaX-type) molecular sieve.
Technical Parameter
| Molecular Sieve 13X Typical Physical Properties |
| Items | Unit | 8*12 Mesh | 4*6 Mesh |
| Bead Size | mm | 1.6-2.5 | 3.0-5.0 |
| Bulk Density | g/ml ≥ | 0.68-0.85 | 0.65-0.80 |
| Equilibrium Water Capacity @ 25℃ | wt% ≥ | 24.0-27.0 | 24.0-27.0 |
| Equilibrium Carbon Dioxide Capacity | wt% ≥ | 18 | 18 |
| Heat of Adsorption | BTU/lb of H2O | 1800 | 1800 |
| Crush Strength | Point Contact | N ≥ | 30-80 | 80-130 |
| Variation Coefficient | - | 0.3 | 0.3 |
| Attrition Rate | wt% ≤ | 0.1 | 0.1 |
| Size Qualification | % ≥ | 97 | 97 |
| Package Moisture | wt% ≤ | 1.5 | 1.5 |
| The interval value of the indexes above are on the basis of the different grade of Molecular Sieve 13X |
Application of 13x molecular sieve
1) Air separation plant gas purification, gas separation,removal of water and carbon dioxide
2) Natural gas, liquefied petroleum gas, liquid hydrocarbon drying and desulfurization
3) General gas deep drying
Our Package
1. 25 Kg/Carton Barrel
2. 150 Kg/ Sealed Iron Drum
Storage
The molecular sieve shall be stored at room temperature, in which the relative humidity is not exceed 90%, and be not exposed in air, and prevented against water, acids and alkalizes.
